PUMPMAN BOVEM 70 SOLAR PUMP COMBO (Max Submersible Depth - 50m under water)
The Pumpman Solar Combo is supplied with 2 A-Grade Renewsys Solar Panels for optimum performance and long life operation.
This solar pump combo includes:
Pump & Motor, MPPT Controller, 1 x Level Probe with 70m cable, Splicing Kit, Solar Cable with Male & Female MC4 Connectors and Solar Panels.
The flow levels range between 3350 to 1050 liters per hour with the specific panel configuration at maximum power. (Cut-off Head 70m)
The pump controller can be fitted with batteries when after hour pumping is required. It is fitted with adjustable speed control to adjust flow levels as well as a borehole level control timer.
INCLUDED IN COMBO
- Pump & Motor
- Mppt Solar Pump Controller
- Solar Panel Cable 1.5m red and black
- Water level sensors x 1
- Cable Splicing Kit
- 2 x 340 Watt Renewsys (Poly) Multi Crystalline Solar Panels (A Grade)
- Instruction Manual & Quick Connection Guide
Submersible cable (NOT INCLUDED)
SPECIFICATIONS
- Voltage - 48 Volt
- Power - 500 Watt
- DC Motor - Oil cooled / Brush-less
- Motor Outer Shell - Stainless Steel
- Pump Outer Shell - Stainless Steel
- Impeller style - Screw Type (Helical Rotor)
- Impeller material - Stainless Steel / Rubber
- Bearing - Ball Bearing
- Max Flow Rate - 3300 l/hr
- Max Head - 50m
- Outlet size - 1"
-
Outlet -Stainless steel
SOLAR PV CONFIGURATION:
- 2 x 340 Watt Renewsys A Grade Panels
WARRANTY
Solar Panel Warranty - 10 Years + 25 Year Yield @ 80%+
Pump Controller - 1 Year (Terms & Conditions as per Installation Guide)
